Weights and Measurements

• Dimensions (Approx.) : "10 7/8" x 11 7/8" x 14 15/16" (275 x 300 x 380mm) (excluding extruding parts, 21 7/8" (555 mm) in depth with paper tray)"

• Weight (Approx.) : 24lbs 4oz (11kg) excluding the 5.6oz (0.16Kg) paper tray


Hardware

• LCD Panel Type : "8" touch-sensitive TFT color display panel (640 x 480 pixels, RGB)²"

• Media Slot : "Memory Stick (1): (Memory Stick®, Memory Stick PRO™, Memory Stick Duo™ and Memory Stick PRO Duo™ media compatible) SD Memory Card (1) MultiMediaCard (1) CompactFlash® (Type I / II) (1) xD-Picture Card (1) SmartMedia (1)"


General

• Power Consumption : 3.0 to 1.3A

• Power Requirements : AC 100 to 240V; 50/60Hz

• Operating Humidity : 20% to 80%

• Operating Temperature : 5°C to 35°C (41°F to 95°F)

• Safety Standards : UC version: UL60950-1 listed CSA C22.2 No.60950-1; CE Version: EN60950-1

• Supported Peripherals : Microsoft Windows 2000; XP Professional; XP Home Edition

• Pixel Gross : "2UPC-C15: 1,536 x 2,148 dots 2UPC-C14: 1,248 x 1,848 dots 2UPC-C13: 1,100 x 1,536 dots (the top, bottom, right, left portions will not be printed by about 2mm)"

• Printing Sizes : "2UPC-C15: 5" x 7" (127 x 178 mm) 2UPC-C14: 4" x 6" (102 x 152 mm) 2UPC-C13: 3.5" x 5" (89 x 127 mm)"

• Printing System : Dye Sublimation Thermal Transfer

• Printing Time : "2UPC-C15: Approximately 17 seconds¹ 2UPC-C14: Approximately 16 seconds¹ 2UPC-C13: Approximately 13 seconds¹"

• Time/Capacity : "2UPC-C15: 172 prints per roll/ribbon cartridge 2UPC-C14: 200 prints per roll/ribbon cartridge 2UPC-C13: 300 prints per roll/ribbon cartridge"

• Type of Use : "Paper Feed Method: Roll paper, Automatic loading from paper holder Ink Supply Method: Ink ribbon cartridge"


Power

• Power Requirements : 100 to 240V AC, 50/60Hz


Image Performance

• Compatible Image File Format : JPEG:; JFIF 4:4:4; 4:2:2; 4:2:0 (baseline JPEG); Exif 2.2.1 compatible DCF 2.0 compatible; Tiff: Exif 2.2.1 compatible (Tiff-RGB non compressed); BMP: 24 bit Windows format; (Some versions of the file formats may not be compatible)

• Image Adjustment : Crop; Color adjust; Filter (Sepia / B&W)

• Print Order When Print From Memory Cards : Selected image; All image; Index; Border Composition; Split Image


Printing Performance

• Printing Method : Dye Sublimation Thermal Transfer

• Resolution : 300 dpi

• Print Size : 2UPC-C15: 5 x 7 inches (127 x 178 mm); 2UPC-C14: 4 x 6 inches (102 x 152 mm); 2UPC-C13: 3.5 x 5 inches (89 x 127 mm)

• Print Capacity : 2UPC-C15: 172 prints per roll/ribbon cartridge; 2UPC-C14: 200 prints per roll/ribbon cartridge; 2UPC-C13: 300 prints per roll/ribbon cartridge

• Printing Time : 2UPC-C15: Approximately 17 seconds; 2UPC-C14: Approximately 16 seconds; 2UPC-C13: Approximately 13 seconds

• Paper Feed Method : Roll paper; Automatic loading from paper holder

• Image Pixels Transferred : 2UPC-C15: 1536 x 2148 dots; 2UPC-C14: 1248 x 1848 dots; 2UPC-C13: 1100 x 1536 dots

• Ink Supply Method : Ink ribbon cartridge

• Gradation : 256 levels (8 bits) each for Yellow; Cyan; Magenta

• Interface : Memory Stick; Memory Stick x1 (Memory Stick; Memory Stick PRO; Memory Stick Duo; Memory Stick PRO Duo compatible); SD Memory Card; MultiMediaCard x 1; CompactFlash (Type I / II) x 1; xD-Picture Card x 1; SmartMedia x 1; Expansion Slot; CompactFlash (Type I / II) x 1; PC Connection; USB(B) x 1 for PC: Hi-Speed USB (USB 2.0); USB Host Port; USB(A) x 1 for mass storage class device: USB flash memory compatible; Expansion Terminal; RS-232C (D-sub 9-pin) x 1 for future peripheral support


Operating Conditions

• Operating Humidity : 20% to 80%

• Operating Temperature : 5°C to 35°C (41°F to 95°F)


Convenience

• Image Quality Mode : Crop, Color adjust, Filter (Sepia, B&W)


Graphics

• Format(s) Supported : "JPEG: JFIF 4:4:4, 4:4:2, 4:2:0 (baseline JPEG), Exif 2.2.1 compatible, DCF 2.0 compatible TIFF: Exif 2.2.1 compatible (TIFF-RGB non compressed) BMP: 24 bit Windows format (Some versions of the file formats may not be compatible)"


LCD Display

• Screen Size : 8-inch touch sensitive TFT color display


Inputs and Outputs

• RS232 Control : External control interface (D-SUB 9-pin connector) for future peripheral support

• USB Port(s) : 1 [USB(B) for PC: Hi-Speed USB (USB 2.0)]


Software

• Bundled Software : Printer Driver for Microsoft® Windows 2000, XP Home Edition and XP Professional


Safety Regulation

• Regulation Compliance : UC version: UL60950-1, listed CSA C22.2 No.60950-1 CE Version: EN60950-1
